Switch Gestionado D-Link DGS-1210-08P/ 8 Puertos/ RJ45 10/100/1000/ SFP/ PoE

  Marca D-Link Modelo DGS-1210-08P/E Especificaciones - 8 puertos 10/100/1000 Mbps - 2 Puertos SFP Standards - IEEE 802.3 compliant - IEEE 802.3u compliant - IEEE 802.3ab compliance - Soporta Half/Full-duplex operation at 10/100Mbps - Soporta Full-duplex operation at 1000Mbps - Soporta Auto-Negotiation for each port - Auto MDI/MDIX - IEEE 802.3x Flow Control support - IEEE 802.3az compliant Rendimiento:   20Gbps - Max.velocidad envío   14.9 Mpps - Tamaño tabla MAC   16K Entries - Packet Buffer   6Mbits - Jumbo Frame   Hasta 13,000 Bytes - Alimentación:   110 to 240 VAC, 50/60HZ internal universal power supply - Max.Consumo   60 Watts - Consumo Standy   5.6 Watts - Sin ventilador - Nivel acústico:   0 dBA - Dimensions (W x D x H)   280 x 180 x 44 mm   19-inch standard rack   1U - Peso:   0.42kg - LEDs   Power (per device)   Link/Activity/Speed/PoE (per 10/100/1000 Mbps port)   Link/Activity/Speed (per SFP port)   Button to switch LED display mode between PoE and Link/ActivityPower (per device) - Certifications   CE Class A   cUL, LVD - MTBF   503,585 Hours (DGS-1100-08) Funciones L2 - MAC Address Table: 16K - Flow Control     802.3x Flow Control     HOL Blocking Prevention - Jumbo Frame up to 13,000 Bytes - IGMP Snooping     IGMP v1/v2 Snooping     IGMP Snooping v3 Awareness     Supports 256 IGMP groups     Supports at least 64 static multicast addresses     IGMP per VLAN     Supports IGMP Snooping Querier - MLD Snooping1     Supports MLD v1/v2 awareness     Supports 256 groups     Fast Leave - Spanning Tree Protocol     802.1D STP     802.1w RSTP - Loopback Detection - 802.3ad Link Aggregation     DGS-1210-10P: Max. 5 groups per device/8 ports per group     DGS-1210-20: Max. 10 groups per device/8 ports per group     DGS-1210-28/28P: Max. 14 groups per device/8 ports per group     DGS-1210-52: Max. 26 groups per device/8 ports per group     DGS-1210-16/24/48: Max. 8 groups per device/8 ports per group - Port Mirroring     One-to-One, Many-to-One     Supports Mirroring for Tx/Rx/Both - Multicast Filtering     Forwards all unregistered groups     Filters all unregistered groups     LLDP, LLDP-MED VLAN - 802.1Q Tagged VLAN - VLAN Group     Max. 256 static VLAN groups     Max. 4094 VIDs - Management VLAN - Asymmetric VLAN - Auto Voice VLAN     Max. 10 user-defined OUI     Max. 8 default OUI - Auto Surveillance VLAN Quality of Service (QoS) - 802.1p Quality of Service - Queue Handling     Strict     Weighted Round Robin (WRR) - 8 queues per port - Bandwidth Control     Port-based (Ingress/Egress, min. granularity for 10/100/1000Base-T ports is 15 Kb/s) - CoS based on     802.1p Priority Queues     DSCP     ToS     TCP/UDP port number     IPv6 traffic class1 Access Control List (ACL) - Max. 50 profiles - Max. 200 rules shared by profiles - Single or multiple ports (each rule) - ACL based on     MAC Address     IPv4 Address (ICMP/IGMP/TCP/UDP)     IPv6 Address (ICMP/TCP/UDP)1     802.1p     DSCP     Ether type     IPv6 traffic class1 - ACL Actions     Permit     Deny Seguridad - Port Security     Supports up to 64 MAC addresses per port - Broadcast/Multicast/Unicast Storm Control - Static MAC - D-Link Safeguard Engine - DHCP Server Screening - Trusted Host - ARP Spoofing Prevention     Max. 64 entries - SSL     Supports v1/v2/v3     Supports IPv4/IPv6 - Traffic Segmentation - Smart Binding1     Discover connected devices and click to bind     ARP Packet Inspection: 512 entries     IP Packet Inspection: 128 entries     Supports DHCP Snooping AAA - 802.1X Port-based Authentication     Supports RADIUS Server     Supports EAP, OTP, TLS, TTLS, PEAP OAM - Cable Diagnostics - Factory Reset MIB - 1213 MIB II - 1493 Bridge MIB - 1907 SNMP v2 MIB - 1215 Trap Convention MIB - 2233 Interface Group MIB - D-Link Private MIB - Power-Ethernet MIB - LLDP MIB - D-Link ZoneDefense MIB1 RFC Standard Compliance - RFC 783 TFTP - RFC 854 Telnet Server - RFC 951 BootP/DHCP Client - RFC 1157 SNMP v1, v2, v3 - RFC 1213 MIB II, IF MIB - RFC 1215 MIB Traps Convention - RFC 1350 TFTP - RFC 1493 Bridge MIB - RFC 1542 BootP/DHCP Client - RFC 1769 SNTP - RFC 1901 SNMP v1, v2, v3 - RFC 1907 SNMP v2 MIB - RFC 1908 SNMP v1, v2, v3 - RFC 2068 FCS - RFC 2131 BootP/DHCP Client - RFC 2138 RADIUS Authentication - RFC 2139 RADIUS Authentication - RFC 2233 Interface Group MIB - RFC 2246 SSL - RFC 2475 - RFC 2570 SNMP v1, v2, v3 - RFC 2575 SNMP v1, v2, v3 - RFC 2598 CoS - RFC 2616 FCS - RFC 2618 RADIUS Authentication - RFC 2819 RMON v1 - RFC 2865 RADIUS Authentication - RFC 3164 System Log - RFC 3195 System Log - RFC 3411-17 SNMP - RFC 3621 Power Ethernet MIB Gestión - Multi-Language Web-based GUI     English (default)     Simplified Chinese1     Traditional Chinese1     French1     German1     Italian1     Japanese1     Portuguese1     Russian1     Spanish1 - SmartConsole Utility2 - Simplified CLI - Telnet Server - TFTP Client - IPv6 Neighbor Discovery - Configurable MDI/MDIX - SNMP     Supports v1, v2, v3 - SNMP Trap - System Log     Max. 500 log entries - BootP/DHCP Client - D-Link Network Assistant support1 - SNTP - ICMPv6 - IPv4/v6 Dual Stack1 - DHCP Auto Configuration - RMON v1 D-Link Green 3.0 Technology - Power Saving by:     Link Status     Cable Length detection     LED or Port Shutoff     Port Standby mode     System Hibernation mode     Time-based PoE (PoE model only) Fecha de revisión 13-06-2022 por MPM
