Gigabyte Placa Base B850M D3HP mATX AM5

Marca Gigabyte Modelo B850M D3HP Plataforma - Micro ATX Form Factor; 24.4cm x 24.4cm Chipset - AMD B850 CPU Soportados - AMD Socket AM5, support for:   AMD Ryzen™ 9000 Series Processors   AMD Ryzen™ 8000 Series Processors   AMD Ryzen™ 7000 Series Processors Memoria - Support for DDR5 8200(OC) / 8000(OC) / 7800(OC) / 7600(OC) /   7200(OC) / 7000(OC)/6800(OC) / 6666(OC) / 6600(OC) / 6400(OC) /   6200(OC) / 6000(OC) / 5600(OC) / 5200 / 4800 / 4400 MT/s memory modules - 4 x DDR5 DIMM sockets supporting up to 256 GB (64 GB single DIMM capacity) of system memory - Dual channel memory architecture - Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules - Support for AMD EXtended Profiles for Overclocking (AMD EXPO™) and Extreme Memory Profile (XMP) memory modules Slots Expansión - 1 x PCI Express x16 slot (PCIEX16), integrated in the CPU:   AMD Ryzen™ 9000/7000 Series Processors support PCIe 5.0 x16 mode   AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x8 mode   AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4 mode - Chipset:   1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x4 (PCIEX4) Gráficos - Integrated Graphics Processor with AMD Radeon™ Graphics support:   1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz * Support for HDMI 2.1 version, HDCP 2.3, and HDR. ** Support for native HDMI 2.1 TMDS compatible ports. - 2 x DisplayPorts, supporting a maximum resolution of 3840x2160@144 Hz * Support for DisplayPort 1.4 version. Puertos E/S, Conectores Conectores Internos - 1 x 24-pin ATX main power connector - 1 x 8-pin ATX 12V power connector - 1 x CPU fan header - 1 x CPU fan/water cooling pump header - 1 x system fan header - 1 x system fan/water cooling pump header - 2 x addressable RGB Gen2 LED strip headers - 1 x RGB LED strip header - 2 x M.2 Socket 3 connectors - 4 x SATA 6Gb/s connectors - 1 x front panel header - 1 x front panel audio header - 1 x USB Type-C® header, with USB 3.2 Gen 1 support - 1 x USB 3.2 Gen 1 header - 2 x USB 2.0/1.1 headers - 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0/GC-TPM2.0 SPI V2 module only) - 1 x reset jumper - 1 x Clear CMOS jumper Panel Trasero - 1 x HDMI port (Note) - 2 x DisplayPorts (Note) - 1 x PS/2 keyboard/mouse port - 1 x Q-Flash Plus button - 1 x USB Type-C® port, with USB 3.2 Gen 1 support - 3 x USB 3.2 Gen 1 ports - 2 x USB 2.0/1.1 ports - 1 x RJ-45 port - 3 x audio jacks Otras Características Almacenamiento - 1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 2580/2280 SSDs:   AMD Ryzen™ 9000/7000 Series Processors support PCIe 5.0 x4/x2 SSDs   AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs   AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4/x2 SSDs - 1 x M.2 connector (M2B_CPU), integrated in the CPU, supporting Socket 3, M key, type 22110/2280 SSDs:   AMD Ryzen™ 9000/7000 Series Processors support PCIe 4.0 x4/x2 SSDs   AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs   AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x2 SSDs - 4 x SATA 6Gb/s connectors - RAID 0, RAID 1, RAID 5, and RAID 10 support for NVMe SSD storage devices   * RAID 5 is only available on AMD Ryzen™ 9000 Series Processors. - RAID 0, RAID 1, and RAID 10 support for SATA storage devices USB - CPU:   1 x USB Type-C® port on the back panel, with USB 3.2 Gen 1 support   1 x USB 3.2 Gen 1 port on the back panel   1 x USB 2.0/1.1 port on the back panel - Chipset:   1 x USB Type-C® port with USB 3.2 Gen 1 support, available through the internal USB header   4 x USB 3.2 Gen 1 ports (2 ports on the back panel, 2 ports available through the internal USB header)   5 x USB 2.0/1.1 ports (1 port on the back panel, 4 ports available through the internal USB headers) Audio - Realtek® Audio CODEC - High Definition Audio - 2/4/5.1/7.1-channel LAN - Realtek® GbE LAN chip (1 Gbps/100 Mbps/10 Mbps) Fecha Revisión 13-06-2025 por DR
