Sai ovislink krypton c60 chasis 60 kva trifasico sin baterias

Capacity 10-200KVAMain InputInput voltage "380V/400V/415V(line to line)220V/230V /240V(line to neutral)"Input frequency 50/60HzPower factor >,0.99Input voltage window -40%~+25%Frequency window 40-70HZBatteryBattery voltage ±240VDCCharger power 20%*PowerCharger voltage precision 1%BypassBypass voltage "380V/400V/415V, three phase220V/230V/240V, one phase"Bypass voltage window -20%-+15%, full load, settableBypass overload capabiltiy 125%, long time operation125%<, load <,130%, last for more than 1 hour130%>,1000%, last for more than 100msOutputOutput voltage "380V/400V/415V, three phase220V/230V/240V, one phase"Voltage precision ±0.5% (balance load),±1% (unbalance load)Voltage THD(Total Harmonic Distortion) THD<,1%(linear load),THD<,5%(nonlinear load)Power factor 0.8Phase tolerance 120°±0.5° (balance and unalance load)Crest factor 3:1Overload capabiltiy 105%,long time operation110%, transfer to bypass after 1hour125%, transfer to bypass after 10 minutes150%, transfer to bypass after 1 minute>,150%, transfer to bypass after 200msSystemSystem efficiency Normal mode: 95%ECO mode: 99%Battery mode efficiency 95%Display LCD+LED, Touch screen and keyboardIP class IP20Interface (Communication Ports ) RS232,RS485,Dry contacts,SNMP card,EPO,GeneratorinterfaceInstallation/Connection Top or bottom cable connectionOperation temperature 0-40Storage temperature -25~70Relative humidity 0-95% (non-comdensing)Noise(dB) <,55dBWeight(KG) 6-module cabinet RM060/10, RM090/15, RM120/20150KG10-module cabinet RM100/10, RM150/15, RM200/20180KGPM10 10KVA: 20KGPM15 15KVA: 21KGPM20 20KVA: 22KGDimension(W*D*H)(mm) 6-module cabinet 600*900*160010-module cabinet 600*900*2000Module 400*600*133 (10KVA/15KVA/20KVA)
